GE Fanuc IC697CPU771

Image for IC697CPU771

Geplc.com sells surplus and refurbished products which are sourced through independent channels. All warranties and support, if applicable, are with geplc.com and not the manufacturer. Geplc.com is not an authorized distributor or representative for the listed manufacturers and makes no representations as to any quality control performed by any listed manufacturer on the products. Read more

Geplc.com sells surplus and refurbished products which are sourced through independent channels. All warranties and support, if applicable, are with geplc.com and not the manufacturer. Geplc.com is not an authorized distributor or representative for the listed manufacturers and makes no representations as to any quality control performed by any listed manufacturer on the products.

Some of the products sold by geplc.com may come with firmware installed on them. Geplc.com makes no representation as to your ability or right to download, obtain, or use any firmware provided by the product's manufacturer. To the extent you wish to use such firmware, it is your responsibility to comply with the terms of any applicable license or other such agreement related to the download, installation, or use of the firmware. Geplc.com makes no representation that the version of the firmware that is installed on any product it sells is appropriate for your needs or use. Further, geplc.com. does not sell, re-sell, or license software that may be needed to operate certain hardware and customers must obtain any necessary software licensing, maintenance, or upgrades from the manufacturer or other authorized source. To the extent any of the products sold by geplc.com requires software for operation, you acknowledge that geplc.com does not sell or license such software and that it is solely your responsibility to obtain the software or a proper license to use it from authorized sources. Read less

Part Number IC697CPU771
Product Line Series 90-70
Manufacturer GE Fanuc

Key Features

  • This CPU module is single slot, and offers 12MHz with the 80C186 microprocessor
  • It supports the IC660/IC661 I/O and IC697 I/O
  • It includes a three position operation mode switch and three status LED's

Description

This GE Fanuc series 90-70 expandable, single slot, CPU with 2K inputs and outputs and supports up to 8K analog. It utilizes a 12Mhz, 80C186 microprocessor and operates at 0.4 microseconds per boolean function. It uses either Windows or MS-DOS based software for programming. The data and program memory are both configurable.

GE_REMAN
icon-check
$828
icon-check
9 in stock
icon-thumbs-up
2 Year GEPLC.com Warranty
REPAIR
icon-check
$575
icon-check
5 in stock
icon-thumbs-up
2 Year GEPLC.com Warranty

Technical Specifications

Block Type Single Slot CPU
Number of Slots 1
Number of Points 2K inputs and outputs
Serial Ports 1
Current Required 1.1 Amps
Block Type Single Slot CPU
Number of Slots 1
Number of Points 2K inputs and outputs
Serial Ports 1
Current Required 1.1 Amps

Common Misspellings

Manufacturer Part Numbers (MPNs) are often difficult to read. Here are some commonly mistaken versions for the IC697CPU771:

  • IC697CPU77I
  • ICG97CPU771
  • ICG97CPU77I
  • 1C697CPU771
  • 1C697CPU77I
  • 1CG97CPU771
  • 1CG97CPU77I
typing

Variants

Minor product variations are often made by manufacturers, these variants are often referred to as “series” or “revisions”. In a few cases, the revision or series of your equipment will not impact you. At geplc.com, we are well-acquainted and fully capable to work with most variants of the IC697CPU771.

Revisions and series tend to be specified in an ambiguous fashion, leading to some confusion over how each variant is named. Here are several of the variants of the IC697CPU771 that we are familiar with and the many ways they may be written:

Series A
  • IC697CPU771A

Series B
  • IC697CPU771B

Series C
  • IC697CPU771C

Series D
  • IC697CPU771D

Series E
  • IC697CPU771E

Series F
  • IC697CPU771F

Series G
  • IC697CPU771G

Series H
  • IC697CPU771H

Series I
  • IC697CPU771I

Series J
  • IC697CPU771J

Series K
  • IC697CPU771K

Series L
  • IC697CPU771L

Series M
  • IC697CPU771M

Series N
  • IC697CPU771N

Series O
  • IC697CPU771O

Series P
  • IC697CPU771P

Series Q
  • IC697CPU771Q

Series R
  • IC697CPU771R

Series S
  • IC697CPU771S

Series T
  • IC697CPU771T

Series U
  • IC697CPU771U

Series V
  • IC697CPU771V

Series W
  • IC697CPU771W

Series X
  • IC697CPU771X

Series Y
  • IC697CPU771Y

Series Z
  • IC697CPU771Z

Series JU
  • IC697CPU771-JU

Series KU
  • IC697CPU771-KU
