GE Fanuc IC693MDL742

Image for IC693MDL742

Geplc.com sells surplus and refurbished products which are sourced through independent channels. All warranties and support, if applicable, are with geplc.com and not the manufacturer. Geplc.com is not an authorized distributor or representative for the listed manufacturers and makes no representations as to any quality control performed by any listed manufacturer on the products. Read more

Geplc.com sells surplus and refurbished products which are sourced through independent channels. All warranties and support, if applicable, are with geplc.com and not the manufacturer. Geplc.com is not an authorized distributor or representative for the listed manufacturers and makes no representations as to any quality control performed by any listed manufacturer on the products.

Some of the products sold by geplc.com may come with firmware installed on them. Geplc.com makes no representation as to your ability or right to download, obtain, or use any firmware provided by the product's manufacturer. To the extent you wish to use such firmware, it is your responsibility to comply with the terms of any applicable license or other such agreement related to the download, installation, or use of the firmware. Geplc.com makes no representation that the version of the firmware that is installed on any product it sells is appropriate for your needs or use. Further, geplc.com. does not sell, re-sell, or license software that may be needed to operate certain hardware and customers must obtain any necessary software licensing, maintenance, or upgrades from the manufacturer or other authorized source. To the extent any of the products sold by geplc.com requires software for operation, you acknowledge that geplc.com does not sell or license such software and that it is solely your responsibility to obtain the software or a proper license to use it from authorized sources. Read less

Part Number IC693MDL742
Product Line Series 90-30
Manufacturer GE Fanuc

Key Features

  • It has a tripped electronic short circuit protection indicator.
  • The outer surface allows for recording of circuit identification information
  • It has LED indicators which are used to display the ON / OFF status of each point

Description

This GE Fanuc series 90-30 Positive Logic 1 amp Electronic Short Circuit Protection Output module comes with a total of 16 points of output. These points are all arranged in 2 individual banks of 8. There is a standard power output terminal shared by the output points of each group. This output module utilizes positive logic features and charactaristics.

GE_NEW
icon-check
$1295
icon-check
2 in stock
icon-thumbs-up
2 Year GEPLC.com Warranty
GE_REMAN
icon-check
$695
icon-check
14 in stock
icon-thumbs-up
2 Year GEPLC.com Warranty
REPAIR
icon-check
$626
icon-check
10 in stock
icon-thumbs-up
2 Year GEPLC.com Warranty

Technical Specifications

Block Type Positive Logic 1 Amp Electronic Short Circuit Protection (ESCP) Output module
Rated Voltage 12/24 volts DC
Number of Outputs 16 outputs
Output Voltage Range: 12 to 24 volts DC (+20%, -15%)
Output current 1.0 Amps
Block Type Positive Logic 1 Amp Electronic Short Circuit Protection (ESCP) Output module
Rated Voltage 12/24 volts DC
Number of Outputs 16 outputs
Output Voltage Range: 12 to 24 volts DC (+20%, -15%)
Output current 1.0 Amps

Common Misspellings

Manufacturer Part Numbers (MPNs) are often difficult to read. Here are some commonly mistaken versions for the IC693MDL742:

  • ICG93MDL742
  • 1C693MDL742
  • 1CG93MDL742
typing

Variants

Minor product variations are often made by manufacturers, these variants are often referred to as “series” or “revisions”. In a few cases, the revision or series of your equipment will not impact you. At geplc.com, we are well-acquainted and fully capable to work with most variants of the IC693MDL742.

Revisions and series tend to be specified in an ambiguous fashion, leading to some confusion over how each variant is named. Here are several of the variants of the IC693MDL742 that we are familiar with and the many ways they may be written:

Series A
  • IC693MDL742A

Series B
  • IC693MDL742B

Series C
  • IC693MDL742C

Series D
  • IC693MDL742D

Series E
  • IC693MDL742E

Series F
  • IC693MDL742F

Series G
  • IC693MDL742G

Series H
  • IC693MDL742H

Series I
  • IC693MDL742I

Series J
  • IC693MDL742J

Series K
  • IC693MDL742K

Series L
  • IC693MDL742L

Series M
  • IC693MDL742M

Series N
  • IC693MDL742N

Series O
  • IC693MDL742O

Series P
  • IC693MDL742P

Series Q
  • IC693MDL742Q

Series R
  • IC693MDL742R

Series S
  • IC693MDL742S

Series T
  • IC693MDL742T

Series U
  • IC693MDL742U

Series V
  • IC693MDL742V

Series W
  • IC693MDL742W

Series X
  • IC693MDL742X

Series Y
  • IC693MDL742Y

Series Z
  • IC693MDL742Z
