| Part Number | IC693MDL340 |
| Product Line | Series 90-30 |
| Manufacturer | GE Fanuc |
Key Features
- There are LED indicators located at the top of the module which indicates the on/off condition of every point.
- It provides a high-degree of inrush current, making its outputs advisable for controlling a great variety of loads
- There is an RC snubber in place for each output to protect against transient electrical noise on the power line
Description
This GE Fanuc series 90-30 AC output module has 16 output points in two isolated groups with each group having eight points. Each of these groups has a separate common. These groups can be used with independent AC supply phases. Both commons can also be powered with the same supply.
Technical Specifications
| Block Type | Output module |
| Rated Voltage | 120 volts AC |
| Number of Outputs | 16 inputs |
| Frequency | 50/60 Hz |
| Output Current | 0.5 A per point |
| Block Type | Output module |
| Rated Voltage | 120 volts AC |
| Number of Outputs | 16 inputs |
| Frequency | 50/60 Hz |
| Output Current | 0.5 A per point |
